Payment Settings
Integrate various payment gateways, for multiple countries and currencies, into WebinOne for form payments, subscriptions and eCommerce workflows.
Gateway
Here you can view the payment gateways currently configured for your supported countries, access their settings and set up new payment gateway integrations.
You can configure one payment gateway (plus “Pay with PayPal”) for each ‘Currency/Country’ your website supports.
See Site Domain Setting for configuring multiple country domains and/or currencies.
The ‘Currency/Country’ you assign here for the payment gateway will determine when this gateway is used for the site user (based on the domain they are visiting your site on).
Below are further details and setup instructions for each supported payment gateway.
Supported Gateways
OVERVIEW
SETUP
Stripe
Log into your Payment Gateway account to gather the credentials required (as displayed in the WebinOne admin) in order to set up the gateway integration.
You may need to check the gateway provider’s help documentation or contact their support agents to determine this information.
At time of writing this documentation, the gateway's API credentials could be retrieved from your Stripe account "Dashboard" under 'Developers' > 'API keys' and the below screenshots show the corresponding credentials.
Live Endpoints
Test Endpoints
SETTINGS
With this option enabled, the customer's card payment, at time of form submission, is authorised only and the funds will be captured later, after a second step has been completed - such as processing the payment from the Order details pages in the WebinOne admin once the purchase has been delivered, for example.
In this scenario, the Order and any email notifications are generated as normal, however the amount and Order status is set to “Pending”. Once the payment has been processed successfully the status is set to “Success”.
If the payment fails, is canceled via the admin, or is not processed within the 7 days hold period, the order status will be set to “Canceled”.
Orders with failed payments can be amended by adding manual “cash” payments against them via the Order detail page, or by initiating the Deferred Payment workflow.
If the order consists of only digital/downloadable products then this Two-step payment flow will be ignored and the default, Instant payment flow will be used.
APPEARANCE
These styling/layout options provide a way of customising this gateway's interface elements to better suit your site's design.
true since you are typically already collecting a full billing address or postal code in the payment form. However, if not, deselect this checkbox to have the payment provider collect the postal code (which may be required).Default or Solid.eWay
Currently, eWay's Rapid API implementation does not allow recurring payment methods.
Log into your Payment Gateway account to gather the credentials required (as displayed in the WebinOne admin) in order to set up the gateway integration.
You may need to check the gateway provider’s help documentation or contact their support agents to determine this information.
At time of writing this documentation, the gateway's API credentials could be retrieved from your "MYeWAY Business Centre" account under 'My Account' > 'API Key' and the below screenshot shows the corresponding credentials.
eWay’s sandbox test environment is a completely separate account that you’ll need to sign up to as a developer, using a different email address to that assigned to any live eWay account. More information can be found in the eWay help articles for Sandbox accounts here.
SETTINGS
Production
Instructs the gateway to use the live production interface for accepting real transactions. Typically used for live sites ready for accepting real-world payments.
Sandbox
Instructs the gateway to use the test/sandbox interface for accepting test transactions. Typically used for trial sites or when setting up/testing a payment flow.
APPEARANCE
These styling/layout options provide a way of customising this gateway's interface elements to better suit your site's design.
Bambora EU
Log into your Payment Gateway account to gather the credentials required (as displayed in the WebinOne admin) in order to set up the gateway integration.
You may need to check the gateway provider’s help documentation or contact their support agents to determine this information.
At time of writing this documentation, the gateway's API credentials could be retrieved by following the instructions here https://developer.bambora.com/europe/checkout/getting-started/access-api.
SETTINGS
With this option enabled, the customer's card payment, at time of form submission, is authorised only and the funds will be captured later, after a second step has been completed - such as processing the payment from the Order details pages in the WebinOne admin once the purchase has been delivered, for example.
In this scenario, the Order and any email notifications are generated as normal, however the amount and Order status is set to “Pending”. Once the payment has been processed successfully the status is set to “Success”.
If the payment fails, is canceled via the admin, or is not processed within the 7 days hold period, the order status will be set to “Canceled”.
Orders with failed payments can be amended by adding manual “cash” payments against them via the Order detail page, or by initiating the Deferred Payment workflow.
If the order consists of only digital/downloadable products then this Two-step payment flow will be ignored and the default, Instant payment flow will be used.
APPEARANCE
There are currently no styling options available for this gateway's input fields.
Authorize.Net
Log into your Payment Gateway account to gather the credentials required (as displayed in the WebinOne admin) in order to set up the gateway integration.
You may need to check the gateway provider’s help documentation or contact their support agents to determine this information.
At time of writing this documentation, the gateway's API credentials could be setup here https://developer.authorize.net/hello_world/sandbox.html.
Authorize.Net requires the customer's first and last name be submitted with payment requests. So if First and Last Name system fields are not present in your payment form an error may be presented and the payment may not be processed.
SETTINGS
Production
Instructs the gateway to use the live production interface for accepting real transactions. Typically used for live sites ready for accepting real-world payments.
Sandbox
Instructs the gateway to use the test/sandbox interface for accepting test transactions. Typically used for trial sites or when setting up/testing a payment flow.
*Potential issue for recurring subscriptions: Authorize.Net does not charge the customer’s card immediately, but rather on the next day at 2:00am (PST) Authorize.Net documentation.
Since secure zone access is based on successful payment, the user may not be granted access until a day later.
These are two options relating to this delayed payment issue.
Give access once payment received only
Leave the delayed payment process in place and wait for the customer to be assigned to the secure zone if a successful payment is made. (Subsequent recurring cycles will be charged without this delay)
Give one-day access before payment received
Apply a one-day subscription, allowing the customer to login initially.
If the charge is later successful then the subscription will be extended for the desired number of days.
APPEARANCE
There are currently no styling options available for this gateway's input fields.
PayPal
Log into your Payment Gateway account to gather the credentials required (as displayed in the WebinOne admin) in order to set up the gateway integration.
You may need to check the gateway provider’s help documentation or contact their support agents to determine this information.
At time of writing this documentation, the gateway's API credentials could be retrieved, after logging into your PayPal account, from PayPal's Developer website here https://developer.paypal.com/, under 'My Apps & Credentials' then creating a new REST API App for either the Sandbox or Live environments.
The WebinOne PayPal integration uses the “PayPal Commerce” service. PayPal PayFlow, PayPal Pro, or other paid services are NOT required for this integration. However, your PayPal account may need to be approved for ‘Advanced Payments’ to allow the payment fields to display. To apply for ‘Advanced Payments’, or if you are experiencing issues with PayPal gateway setup, see the troubleshooting section below for further steps.
Create REST API App
App Credentials
SETTINGS
Production
Instructs the gateway to use the live production interface for accepting real transactions. Typically used for live sites ready for accepting real-world payments.
Sandbox
Instructs the gateway to use the test/sandbox interface for accepting test transactions. Typically used for trial sites or when setting up/testing a payment flow.
APPEARANCE
There are currently no styling options available for this gateway's input fields.
TROUBLESHOOTING
If you are experiencing issues with PayPal gateway setup, such as payment fields are not displaying and you’re seeing an error in your browsers console saying “hosted fields are not eligible”, below are some steps to check to resolve the issue:
- Ensure your developer account is linked/created with the PayPal business account that will be used.
- Create the Sandbox/Live App account/s from the linked developer account.
- The Sandbox/Live App account/s should also be setup as PayPal business accounts and both Sandbox and Live accounts need to be enabled for advanced payments (use this link for more info and to apply)
If you continue to experience issues, reach out to PayPal support to see if there are any issues with your account setup or App credentials.
Pay with PayPal
Log into your Payment Gateway account to gather the credentials required (as displayed in the WebinOne admin) in order to set up the gateway integration.
You may need to check the gateway provider’s help documentation or contact their support agents to determine this information.
At time of writing this documentation, the gateway's API credentials could be retrieved, after logging into your PayPal account, from PayPal's Developer website here https://developer.paypal.com/, under 'My Apps & Credentials' then creating a new REST API App for either the Sandbox or Live environments.
If you are receiving errors when testing PayPal payments, it could be due to your PayPal account still pending approval. Check your PayPal account for any notifications asking for further setup details.
Create REST API App
App Credentials
SETTINGS
Production
Instructs the gateway to use the live production interface for accepting real transactions. Typically used for live sites ready for accepting real-world payments.
Sandbox
Instructs the gateway to use the test/sandbox interface for accepting test transactions. Typically used for trial sites or when setting up/testing a payment flow.
APPEARANCE
There are currently no styling options available for this gateway's input fields.
